Mechanical Ball Float Water Level Exhaust Directional Control Valve
Valve;Structure:Control,Pressure:Low~High Pressure,Media:Water,Application:ductile iron pipe.
| Quick Details | |
| Standard or Nonstandard: | Standard |
| Structure: | Control |
| Pressure: | Low~High Pressure |
| Power: | Solenoid |
| Material: | Casting |
| Temperature of Media: | Low~high Temperature |
| Media: | Water |
| Port Size: | 1"-24" |
| Place of Origin: | China (Mainland) |
| Application: | ductile iron pipe |
| Name: | EO |
| Body material: | CI,DI,Carbon Steel, SS304 |
| Standard: | JIS, AISI, ASTM, GB, DIN, EN |
Name: float valve
Standard or Nonstandard: | Standard | Structure: | Control | Pressure: | Medium Pressure |
| Media: | Water | Port Size: | Standard, DN50-DN400 | Place of Origin: | China (Mainland) |
| Color: | Blue | Seal material: | PTFE, Flexible graphite | Valve body: | control valve |
| Disc: | WCB+stainless Steel | Rotation angle: | 0-90° | Weight: | differenct size |
| Name: | hydraulic remote control float valve | working medium: | water, oil, gas | Surrounding Temperature: | 0°C ~ + 80°C |
| Materials of major parts: | |
| Name of parts | Material of parts |
| Body & cap | Ductile iron |
| Valve seat & valve disc | Brass |
| Valve stem | Stainless steel |
| Spring | Stainless steel |
| Surface | EPOXY |
| Valve sealing | EPDM/NBR |
